TM 1-1520-238-23
4-170
4.54.
NO. 2 ENGINE INSTALLATION – LOWER CONNECTIONS – continued
h. Install starter air tube (19).
(1) Loosen clamp screws (20).
(2) Slide connector (21) on air tube (19) until cen-
tered.
(3) Tighten clamp screws (20).
i. Install bleed tube (22) on elbow fitting (23).
(1) Hold elbow (23). Install nut (24).
j. Inspect (QA).
GO TO NEXT PARAGRAPH
21
20
19
20
M04-2997-6
M04-2997-7
23
24
22
